I'm trying out a modular concept for N-scale (1:160) freighters and container ships. I've popped the first bows and sterns out of resin, and they look good and fit well. Here are some progress shots.

First is a 503' break bulk freighter built in the late 1940s. You can see the 140' cast bow and 103' stern (blue) and the styrene box mid-section of 250' length (grey). The large midship superstructure accommodates 20 passengers and is from the 1947 Beavercove. I've cast all six hatches, the 24 cargo winches, and other deck details, but didn't have time to place them, as I was racing off to Alabama for a few weeks. I've drawn the photoetch railings but haven't sent them out yet. The superstructure is easy to build, once I (or you) have gotten the square windows cut out.



Next is a 435' container ship from the late 1960s. It uses the same bow (which is pretty typical in ship construction, although container ships did go to a bulbous bow early on), a level stern and, for illustration purposes, a 200' center section. It could use a 150'. 250', 300' or even 350' center section and be within modern shipbuilding practices--for mid-sized ships. The shorter versions would be a bit stubby; the longer versions a bit slim. The rear, high superstructure is modeled after a similarly sized ship of the 1970s, still in service. I've drawn and cut the full deck-width folding hatches, but haven't molded them yet. I've also got the photoetch brass railings ready.



Finally, here's the two of them together, showing just two possibilities. The early container ships were converted break bulk freighters, so a container ships with a midship island is perfectly reasonable. So is a container ship with a poop deck and a tall, shallow superstructure near the break between poop and main decks.



I've built a third superstructure--an early Sea Witch style--which I will photograph later. With modular construction, I've had to make a few minor compromises, such as settling on a standard hatch width or cabin height. I'd like to know how folks feel about this approach.

[jeager]

Those look pretty good. The one with the midship deckhouse is reminiscent of US Line's Lancer and Leader class rebuilds, while the other one reminds me of some of Sea-Land's conversions.

[pnolan48]

I forgot to mention, it's 28-1/2 inches long. I stopped counting the cost after the styrene bill hit $30. There's easily $50 in there, counting the Evergreen. Base and internals are .060".

Lee Anne

I realize this is nearly three years late, but I buy 4' x 8' sheets of styrene for about $10 from a plastics dealer. My digital cutter accepts sheets 9" wide, so I cut the sheets by hand into 9" x 48" pieces, and then again into 9" x 24" or 9" x 16" pieces. Thus a 9" x 24" piece costs about $0.50.

I was also tired of paying $4 for a small bottle of liquid glue. So I bought a quart of MEK (methyl ethyl ketone) and a pint of toluol (toluene) at my local hardware store for about $7 total. I mix it 80% MEK to 20% toluol, although the proportions are not critical. A 3 oz bottle costs me about $0.40. My digital cutter works best with 0.020 styrene with a score and snap technique, so I'm often laminating large sheets together once they are cut. The mixture works as well as any commercial formula.

[pnolan48]

Those look pretty good. The one with the midship deckhouse is reminiscent of US Line's Lancer and Leader class rebuilds, while the other one reminds me of some of Sea-Land's conversions.

While I made the container deckhouse generic in terms of measurements to fit a 60' beam ship, the layout is based on a photo of a Sea-Land ship. I draw these structures on my computer, then use a digital cutter to score the 0.020" styrene, then snap the edges and cut out or drill out the interior openings, which are also scored. With this technique I can develop new structures quickly. On this trip to Alabama, I brought along the cutter (it's about the size of a long loaf of bread) and have drawn, cut and assembled a third superstructure and a few different stacks, and drawn a fourth deckhouse during a side trip to Florida for a wedding.
